Product Specs
Label
Value
Motor
Permanent Magnet P/N 11-150-00, Thermally Protected
Port
3/8" NPT
Voltage
115V
Material Of Construction
Plastics (Polypropylene) Valves (Viton) Diaphragm (Viton) Fasteners (Zinc Plated Steel)
Liquid Temperature
170 Degrees Fahrenheit (77 Degrees Centigrade) Max.
Pressure Switch
Adjustable Shut-Off (Range 40-60 PSI) Factory Set @ 60 PSI, Turn on 45 PSI
Check Valve
(2-Way Op.) Prevents Reverse Flow & 6 Ft. Head Forward Flow
Pump Design
Positive Displacement 3 Chamber Diaphragm Pump
CAM
2.5 Degree
